ALPINE S2-A36F

ALPINE S2-A36F
4-channel car amplifier:
60 watts RMS x 4 at 4 ohms
90 watts RMS x 4 at 2 ohms
180 watts RMS x 2 bridged at 4 ohms
Hi-Res Audio Certified (frequency response: 20-40k Hz)
variable high- and low-pass filters (50-400 Hz, 12 dB/octave)
variable mid-bass boost (0-12 dB at 100 Hz) on Ch 3/4
optional wired remote available for Ch 3/4
preamp and speaker-level inputs
speaker-level inputs handle up to 10V
RCA adapters required for speaker-level input
signal-sensing turn-on with speaker-level inputs
wiring and hardware not included with amplifier
8-gauge power and ground leads recommended

RMS Power Output (Watts x Channels): 60 x 4
Peak Power Output (Watts x Channels): ---
Power at 2 Ohms (Watts x Channels): 90 x 4
Bridged Power (Watts x Channels): 180 x 2
Minimum Impedance Bridged: 4
Minimum Impedance Unbridged: 2
Minimum Impedance: 2
Best Frequency Response: 10-40k Hz
THD at Rated RMS Power: ---
Signal to Noise Ratio: ---
Input Voltage: ---
Amplifier Class: D
Low-Pass Crossover Frequency: 50-400 Hz
Low-Pass Slope (dB/octave): 12 dB/octave
High-Pass Crossover Frequency: 50-400 Hz
High-Pass Slope (dB/octave): 12 dB/octave
Bass Boost: 0-12 dB
Bass Boost Frequency: ---
Fan Cooled: ---
Fuse Rating: 40
Speaker Level Inputs: Yes
Preamp Outputs: No
Width (inches): 8-3/4
Height (inches): 2-1/4
Depth (inches): 8-1/4
Low Frequency Response : 50-400 Hz
High Frequency Response : 50-400 Hz
Number of Channels : 4
Frequency Response : 20-40000 Hz
Built In Crossovers : Yes
Amplifier Class : D
Fuse Rating : 40 A
