OG AUDIO OGWS15600A OGWS SERIES 15 IN 600 WATTS 4 OHM – BRONZE

OG AUDIO OGWS15600A
The OGWS15600A is a high performance 15-inch, dual 4-ohm/2-ohm component car subwoofer. The OGWS series dimensions 387*225mm makes for a great daily subwoofer, and was engineered to be extremely efficient and reliable sounding great and getting down., all features are the top technology, the magnet system type are FERRITE, the Featuring a high temperature 2.4-inch copper voice coil and powerful, with black aluminum for 6.11cm diameter, this subwoofer can perform at peak levels for extended periods of time safely
OG WS 15" 600 WATTS RMS 4Ω BRONZE
OG WS 15" 600 WATTS RMS 4Ω BRONZE
OG WS 15" 600 WATTS RMS 4Ω BRONZE
OG WS 15" 600 WATTS RMS 4Ω BRONZE
OG WS 15" 600 WATTS RMS 4Ω BRONZE
OG WS 15" 600 WATTS RMS 4Ω BRONZE
OG WS 15" 600 WATTS RMS 4Ω BRONZE

OG WS 15" 600 WATTS RMS 4Ω BRONZE
Reference : OGWS15600A
The OGWS 15600AD is a high performance 15-inch, dual 4-ohm/2-ohm component car subwoofer. The OGWS series dimensions 387*225mm makes for a great daily subwoofer, and was engineered to be extremely efficient and reliable sounding great and getting down., all features are the top technology, the magnet system type are FERRITE, the Featuring a high temperature 2.4-inch copper voice coil and powerful, with black aluminum for 6.11cm diameter, this subwoofer can perform at peak levels for extended periods of time safely

Share Tweet Pinterest
Security policy
(edit with the Customer Reassurance module)

Delivery policy
(edit with the Customer Reassurance module)

Return policy
(edit with the Customer Reassurance module)

Guarantee safe checkout
cms-banner1
Description Product Details Shipping
The OGWS 15600AD is a high performance 15-inch, dual 4-ohm/2-ohm component car subwoofer. The OGWS series dimensions 387*225mm makes for a great daily subwoofer, and was engineered to be extremely efficient and reliable sounding great and getting down., all features are the top technology, the magnet system type are FERRITE, the Featuring a high temperature 2.4-inch copper voice coil and powerful, with black aluminum for 6.11cm diameter, this subwoofer can perform at peak levels for extended periods of time safely.
Punchy, responsive, and capable of getting low, this 15-inch subwoofer will work great in a variety of applications. Furthermore, it utilizes an advanced cooling structural design which optimizes performance even further. Last but not least comes the premium strength cone material is kraft pulp fiber non-pressed cone and high roll foam surround, which allow for the versatility of this driver to get nice and low while also being responsive.
General Data

OGWS15600AD2

OGWS15600AD4

Overall Dimensions

387*225mm

Nominal Power Handling

600

W

Transient Power 10ms

1200 W

Sensitivity

85.9 dB

86.9 dB

Frequency Response

29-300Hz

Cone Material

Kraft pulp fiber non-pressed cone

Net Weight

7.03 kg

Electrical Data

Nominal Impedance

Dual 2.0Ohm

Dual 4.0Ohm

DC Resistance

Dual 1.9Ohm

Dual 3.2Ohm

Voice Coil and Magnet Parameters

Voice Coil Diameter

61.1 mm

Voice Coil Height

35mm

HE Magnetic Gap Height

8mm

Max.Linear Excursion

13.5 mm

Voice Coil bobbin

Black Aluminum

Voice Coil Wire

Copper

Number Of Layers

4 layers

Magnet System Type

Ferrite

BL Product

16.36 N.A

9.33 N.A

T-S Parameters

Suspension Compliance

Cms

0.11

0.12

Mechanical Q Factor

Qms

6.05

5.47

Electrical Q Factor

Qes

0.75

0.8

Total Q Factor

Qts

0.67

0.7

Moving Mass

Mms

299

267

Eq.Cas Air Load( liters)

VAS

84.85 Liter

99.1Liter

Resonant Frequency

Fs

29

Hz

29

Hz

Effective Piston Area

SD

754.7 cm²
