SUNDOWN AUDIO SALT12

SUNDOWN AUDIO SALT12
SALT-12 DIGITAL MONOBLOCK FEATURES
• Digital Class-D Linkable Mono Block Am• Digital Class-D Linkable Mono Block Amplifier
• Dual MOSplifier
• Dual MOS-FET PWM Power Supply
• 1 Ohm Stable Load
• 24 dB/Octave – Variable Low Pass Filter
• 24 dB/Octave – Variable Subsonic Filter
• 9 dB/Octave – Variable Bass Boost
• 180° Variable Phase Shift
• 4 Way Protection Circuit (Thermal, Voltage, Speaker Short, DC Offset)
• Wired Remote Control with Voltage & Temperature Display and Clipping Indicator
-FET PWM Power Supply
• 1 Ohm Stable Load
• 24 dB/Octave – Variable Low Pass Filter
• 24 dB/Octave – Variable Subsonic Filter
• 9 dB/Octave – Variable Bass Boost
• 180° Variable Phase Shift
• 4 Way Protection Ciruit (Thermal, Voltage, Speaker Short, DC Offset)
• Wired Remote Control with Voltage & Temperature Display and Clipping Indicator

SPECIFICATIONS (Tested @ 14.4v)
2 ohm Linked RMS N/A
1 ohm Mono RMS 12000W
2 ohm Mono RMS 6000W
4 ohm Mono RMS 3000W
Recommended Fuse Rating 2000A
Low Pass Filter (Variable) 35Hz-250Hz
Subsonic Filter (Variable) 10Hz-50Hz
Bass Boost @ 45Hz 0-9dB
Phase Shift Control 0-180 Degrees
Input Sensitivity (+/- 5%) 6v-0.2v
Frequency Response (+/- 1dB) 10Hz-250Hz
S/N Ratio 90dB
Working Voltage 9v-15.5v
T.H.D @ 4ohms < 0.1%
Efficiency @ 4ohms 90% <
Dimensions 37.80″ x 10.08″ x 2.96″
