Xmax = 12mm one-way by 70% BL
Xmech is a hard limit of 25mm one-way (being over 2x the Xmax it is a very generous limit)
RMS Power = 600-watts
Black Aluminum 2.5” voice coil former for superior heat dissipation
High Temperature 4-Layer copper voice coil wire
Stitched-On “Mini-XL” Tinsel Leads to prevent fatigue and failure
Solid Pole with high velocity vent channels machined around the OD
Vented, EMD Cut, Top-Plate Design
Bolt-through motor design to ensure maximum longevity and ruggedness against mechanical failures
** This motor is bolted through the top so the bolts are not visible from the back like several other models.
Magnet ID shorting ring
| Weight | 23 lbs |
|---|---|
| Sub Features | |
| Sub Size |
